Pad Holding Frames
HOLDS FILTERS FIRMLY IN PLACE! CHANGE FILTERS QUICKLY!
New convex grid design permits tuck-in of any filter media around entire perimeter of frame.
Frame may be used for high and/or low efficiency filter media.
Durable 24 gauge steel construction frame uses corrosion-resistance retaining grid (inside grid 1" x 1", 16 Gauge Weld-Wire.)
Angled-Channel steel frame absolutely seals itself against filter media for more efficient operation. Permits easy economical replacement of filter media.
STANDARD SIZES
1/2" Thicknesses
Also Available in all sizes
1" FRAME THICKNESS
NOMINAL SIZE |
ACTUAL SIZES |
12 x 24 x 1 |
11 1/2 x 23 1/2 x 7/8 |
16 x 20 x 1 |
15 1/2 x 19 1/2 x 7/8 |
16 x 25 x 1 |
15 1/2 x 24 1/2 x 7/8 |
20 x 20 x 1 |
19 1/2 x 19 1/2 x 7/8 |
20 x 25 x 1 |
19 1/2 x 24 1/2 x 7/8 |
24 x 24 x 1 |
23 1/2 x 23 1/2 x 7/8 |
2" FRAME THICKNESS
NOMINAL SIZE |
ACTUAL SIZES |
12 x 24 x 2 |
11 1/2 x 23 1/2 x 1 3/4 |
16 x 20 x 2 |
15 1/2 x 19 1/2 x 1 3/4 |
16 x 25 x 2 |
15 1/2 x 24 1/2 x 1 3/4 |
20 x 20 x 2 |
19 1/2 x 19 1/2 x 1 3/4 |
20 x 25 x 2 |
19 1/2 x 24 1/2 x 1 3/4 |
24 x 24 x 2 |
23 1/2 x 23 1/2 x 1 3/4 |
